Key Features & Operational Advantages

• Self-Powered for Remote Missions
  • The Tech: Powered by a built-in High-Power Battery Pack driving a DC Brushless Motor.
  • The Benefit: Delivers up to 4 hours of continuous operation without external power supply. This energy-saving, eco-friendly design ensures your Airship Winch is ready to operate anywhere, from remote deserts to offshore platforms.
• Heavy-Duty Transmission (K-Series)
  • The Tech: Incorporates a robust K-Series Helical-Bevel Gearbox.
  • The Benefit: Provides superior transmission efficiency and high load-bearing capacity. It ensures smooth torque delivery even under heavy tension (up to 8000kg), guaranteeing stable performance during critical launch and recovery phases.
• Real-Time Flight Data Monitoring
  • The Tech: Equipped with integrated Tension Sensors (Force) and Meter Counting Sensors (Length), displaying data on a rugged LCD Screen.
  • The Benefit: Operators can monitor rope tension and deployed length in real-time. This feedback is essential for maintaining flight stability and validating experimental data during dynamic performance tests.
• Precision Control & Safety
  • The Tech: Advanced frequency conversion control with sensor feedback loops.
  • The Benefit: Ensures accurate rope deployment and retrieval speeds. The system guarantees the safety of the aerostat by preventing over-tensioning and allowing for precise altitude adjustments.

Technical Specifications

Application Scenarios

• Pneumatic Load Simulation: Controlled stress testing for airship structures.
• Flight Experimentation: Dynamic performance testing for blimps and balloons.
• Tethering & Recovery: Safe deployment and retrieval of surveillance aerostats and communication platforms.
• Field Operations: Independent operation in off-grid locations.
